AITRIP 1 Pack ESP32 Development Board ESP32-2432S028R WiFi Bluetooth 2.8 Inch 240X320 Smart Display TFT Module Touch Screen for Arduino

Name: AITRIP 1 Pack ESP32 Development Board ESP32-2432S028R WiFi Bluetooth 2.8 Inch 240X320 Smart Display TFT Module Touch Screen for Arduino
Brand: AITRIP
SKU: awhd-us-b0ckyvpwx9
Price: 16.14 USD
Availability: InStock

Brand: AITRIP

Condition: Used

$16¹⁴

$16⁹⁹

-5% Save $0⁸⁵

Updated: 3 days ago

Buy at Amazon.com

Description

The display screen is controllable and can be used for APP remote control, remote environmental data collection and remote. Data , remote parameter setting and other batch development applications. ESP32-2432S028 development board is based on the ESP32-DOWDQ6 controller, low-power, dual-core CPU, clock frequency up to 240MHZ, integrates a wealth of resource peripherals, high-speed SDIO,SPI, UART and other functions Application: Home smart device image transmission, Wireless monitoring, Smart agriculture QR wireless recognition, Wireless positioning system signal, And other IoT applications ESP32 WIFI&Bluetooth Development Board 2.8 " 240*320 Smart Display Screen 2.8inch LCD TFT Module With Touch WROOM; Support: 1: UART/SPI/I2C/PWM/ADC/DAC and other interfaces 2:OV2640 and OV7670 cameras, built-in flash 3:picture WiFI upload 4:TF card 5:multiple sleep modes 6:Embedded Lwip and FreeRTOS 7:STA/AP/STA+AP working mode 8:Smart Config 9:AirKiss one-click network configuration 10:secondary development The ESP32-24325028 development board is based on the company's ESP32-D0WDQ6 controller, with dual core CPU and clock frequency up to 240MHz. It integrates peripherals, high-speed SDO, SP, UART and other functions, and supports automatic download.

Specifications

Working voltage 4.75-5.25V

SPIFlash default 32Mbit

RAM internal 520KB

Wi-Fi 802.11b/g/n/e/i

Bluetooth Bluetooth 4.2BR/EDR and BLE standard

Support interface (2Mbps) UART, SPI, I2C, PWM

Support TF card, maximum support 4G

IO port 9

Serial port rate default 115200bps

Spectrum range 2400 ~2483.5MHz

Antenna form Onboard PCB antenna, gain 2dBi

Image output format: JPEG (only OV2640 support), BMP, GRAYSCALE

Packaging method DIP-16

Transmit power 802.11b: 17±2dBm (@11Mbps)

802.11g: 14±2dBm (@54Mbps)

802.11n: 13±2dBm (@MCS7)

Receiving sensitivity CCK, 1Mbps: -90dBm

CCK, 11Mbps: -85dBm

6Mbps(1/2BPSK): -88dBm

54Mbps (3/464-QAM): -70dBm

MCS7 (65Mbps, 72.2Mbps): -67dBm

Power consumption Turn off the flash: 180mA@5V

Turn on the flash and adjust the brightness to the maximum: 310mA@5V

Deep-sleep: The lowest power consumption can reach 6mA@5V

Moderm-sleep: the lowest can reach 20mA@5V

Light-sleep: the lowest can reach 6.7mA@5V

Security WPA/WPA2/WPA2-Enterprise/WPS

Working temperature -20 ℃~ 70 ℃

Storage environment -40 ℃~ 125 ℃, <90%RH
