UPS15-58FRC Circulator Pump 1/25HP 115V Compatible with Grund-fos 59896343 Hot Water Circulator/radiant heating/hydronic heating/fan coil heating/solar & other system types — Open-Box, 35% Off

【Replacement Part Number】UPS15-58FRC 59896343. 【Parameters】Voltage: 115V. Amperage at Speed 1: 0.55 Amps. Amperage at Speed 2: 0.66. Amps Amperage at Speed 3: 0.75 Amps. Hertz: 60 Hz. Phase 1 Watts at Speed 1: 60W. Watts at Speed 2: 80W. Watts at Speed 3: 87W. Max Pressure: 145 psi. Max Temperature: 230F. Min Temperature: 36F. Flow Range: 0-17 GPM. Head Range: 0-19.5 ft. Horse Power: 1/25HP. Body: Cast Iron. Connections Flanged 1/2", 3/4", 1rdquo, 1-1/4. 【Low Noise Operation】59896343 Featuring a pure copper motor and unique internal design, Enjoy a peaceful home environment without disruptive noises, even in close proximity to your heating zones. 【Adjustable Flow Rate】With three adjustable speed settings, tailor the water circulation speed to your seasonal needs or specific usage requirements. Achieve greater energy efficiency and comfort with ease. 【Excellent Performance】Our UPS15-58FRC Hot Water Circulator Pump Has Built-In Motor Protection, Which Prevents the Motor from Being Damaged in Abnormal Conditions Such as Overload or Short Circuit. When the Motor Runs Beyond the Rated Load, It Will Cut off the Power Supply in Time to Protect the Motor from Damage, So That Your Motor Will Last Longer and Perform Better.

UPS15-58FRC Circulator Pump

This hot water circulator pump is designed to provide quiet, efficient, and reliable circulation for residential and commercial heating systems. Featuring a pure copper motor and unique internal design, it delivers peaceful operation without disruptive noises, even when installed close to living areas or heating zones

Equipped with three adjustable speed settings, you can tailor water circulation speed to seasonal needs or specific usage requirements, achieving greater energy efficiency and comfort with ease. Built-in motor protection prevents damage from abnormal conditions such as overload or short circuit, automatically cutting power to extend motor life and ensure reliable performance

Designed as a compatible replacement for Grundfos UPS15-58FRC, this unit replaces part number 59896343. The flanged connections support multiple pipe sizes, making it a versatile choice for various heating system configurations

Specifications

Replacement Part Number: 59896343

Compatible With: Grundfos UPS15-58FRC

Voltage: 115V

Frequency: 60 Hz

Phase: 1

Amperage: 0.55A (Speed 1) / 0.66A (Speed 2) / 0.75A (Speed 3)

Wattage: 60W (Speed 1) / 80W (Speed 2) / 87W (Speed 3)

Max Pressure: 145 PSI

Max Temperature: 230°F

Min Temperature: 36°F

Flow Range: 0-17 GPM

Head Range: 0-19.5 ft

Horse Power: 1/25 HP

Body Material: Cast Iron

Connections: Flanged (1/2", 3/4", 1", 1-1/4")

Package Includes

1 x UPS15-58FRC Circulator Pump

Note

Please ensure that the product parameters and specifications match your system requirements. Verify voltage, connection size, and temperature ratings before installation
