TSWGTG 1/4" x 40" Stainless Air Compressor Jumper Hose with NPT Adapters — Open-Box, 8% Off

Thread and sealing configuration: Both hose ends feature G1/4 BSPP female swivel fittings with convex spherical seats. The two supplied adapters connect through matching G1/4 BSPP male concave spherical seats and provide 1/4 NPT male threads for installation on compatible machines. Before ordering, verify your machine’s thread size and sealing method.

Spec-first: 1/4" NPT x 40" stainless-steel metal air line and compressor jumper hose for connecting a compressor outlet to an air tank, hard line, air dryer, FRL, regulator, or manifold.

Corrugated stainless core: Annular full-wave construction helps reduce vibration and accommodate thermal movement and minor misalignment while supporting steady airflow for compatible 1/4" compressor discharge and head-pipe applications.

Built for shop environments: Braided protective sleeve helps resist abrasion, dragging, and frame rub; extended crimp ferrules help distribute end stress. Leak-tested stainless-steel construction is rated for 870 PSI working pressure.

What’s included: 1 x 1/4" x 40" stainless-steel braided jumper hose with two G1/4 BSPP female swivel fittings, 2 x matching G1/4 BSPP-to-1/4 NPT male adapters, and 1 x PTFE thread-seal tape roll. Apply the tape only to the NPT threads, wrapping 2–3 turns before tightening.

Built for demanding compressor setups, this 1/4" x 40" Air Compressor Jumper Hose, ID 0.31" and OD 0.53", uses an annular full-wave corrugated stainless-steel core to absorb vibration, accommodate thermal movement, and compensate for minor misalignment while maintaining airflow. A braided protective sleeve adds outer protection against abrasion, dragging, and frame rub—ideal for busy shops where lines are frequently handled or bumped. Extended crimp ferrules help distribute end stress to reduce fatigue and pull-out at the fittings during repeated operation. For quick, clean installation, both hose ends use G1/4 BSPP female swivel fittings with convex spherical seats. The two included adapters connect through matching G1/4 BSPP male concave spherical seats and provide 1/4 NPT male threads for compatible machine ports. The swivel connections help align the hose with less twisting during installation. Use it as a flexible vibration-isolating line between a compressor and an air tank, hard line, air dryer, FRL, regulator, or manifold. Rated for 870 PSI working pressure and leak-tested, this 40" jumper line helps protect rigid plumbing while providing additional routing reach. Installation kit included: Apply the supplied PTFE thread-seal tape only to the 1/4 NPT adapter threads. Wrap 2–3 turns in the direction of the threads before tightening. Do not apply tape to the G1/4 spherical-seat connections. Package includes 1 x 1/4" x 40" jumper hose, 2 x G1/4 BSPP-to-1/4 NPT male adapters, and 1 x PTFE thread-seal tape roll.
