PVC True Union Check Valve, 2'' Slip Swing Full Port Utility, Sch80 Socket Pool Ball for Backflow Prevention

【PVC Ball Check Valve】Schedule 80 PVC ball check valves have a spherical ball inside the valve body which works as a check to allow flow in one direction and close off to prevent back-flow. 【INSTALLATION TIP】PVC union check valves are designed for VERTICAL installations, MUST be used in an upflow position to work properly. Check valves MUST be installed with the valve's flow arrow pointing in the direction of the flow. Do not install valve upside down. （NOTE: NO SPRING) 【PVC Union Check Valve】True union check valve, can be taken apart for cleaning, allows for easy removal without breaking down the piping connection. 【Material】2’’ Slip check valve made of PVC material, O-ring with EPDM material, low-temperature-resistant, impact-resistance, ultraviolet-resistance, rust-resistance. Fits for Schedule 80 2 Inch Pipe. 【Application】PVC Swing Check Valve 2’’(DN50) - Non-return or "one way" valve is ideal for flow control, such as commercial plumbing, aquariums, irrigation, swimming pools, water parks and OEM applications. PVC True Union Check Valve, 2’’ Slip Swing Full Port Utility Check Valve, Sch80 Socket Pool Ball Check Valve for Backflow Prevention
Specification:
For use with: water
Type: check valve
Connection type: Pipe
Connection: Socket
Schedule: 80
O-Ring Material: EPDM
Cracking pressure: less than 5psi
Mounting: horizontal or vertical up-flow
Max pressure: 150psi
Maximum service temperature: 140℉（60℃）
Features:
Engineered for maximum flow, quick response & positive shutoff
Excellent for pool &spa, OEM and general purpose applications
Compact, space-saving design
Suitable for horizontal or vertical up-flow installations
Package:
1Pc PVC union check valve
