Neoteck Clamp Meter 6000 Counts 800A AC (NO DC) Current 600V AC DC Voltage — Open-Box, 6% Off

Ultimate Safety & Overload Protection: Engineered to CAT III 600V safety standards and featuring intelligent anti-burn protection, this clamp meter provides reliable defense against electrical hazards, ensuring user safety when working with mains power and industrial equipment 800A AC Current with 26MM High-Capacity Jaw: Designed for demanding scenarios, the digital clamp meter is equipped with 800A AC current range and 26mm large jaw effortlessly,handling high inrush currents from motors and compressors. This provides essential headroom for accurately measuring startup surges and continuous high loads in HVAC and industrial systems, ensuring both precision and a safer operating margin Smart Auto-Identification & Manual Control: Simplify your work with intelligent auto-identification for AC/DC voltage, continuity, and resistance. For full control, all measurement functions can also be manually selected, making it suitable for both quick checks and complex diagnostics Large Color Display with Analog Bar & Multi-Content Readout: Read measurements clearly on the large, high-contrast color screen, where the fast-response analog bar provides a visual trend of fluctuating signals for quick peak capture. For comprehensive situational awareness, the dual-line display simultaneously shows multiple parameters: view voltage and current alongside frequency, or see your primary measurement with the ambient temperature, enabling faster and safer troubleshooting without switching modes Wide Measurement Range & All-in-One Functionality Clamp Meter: Tackle various electrical tasks with a comprehensive 6000-count clamp multimeter. It accurately measures AC/DC Voltage up to 600V, AC Current up to 800A, Resistance, Continuity, Diode, Capacitance, and Frequency, making it a versatile tool for any professional Essential Pro Features for Enhanced Usability: Work efficiently with built-in productivity features. Non-Contact Voltage (NCV) detection allows for safe live wire checking. The clamp head light and bright backlight illuminate dark work areas, while the Max/Min function helps record peak values during troubleshooting Multiple Applications: This digital clamp meter tackles your most common tasks. Safely troubleshoot house wiring (CAT III 600V rated), check appliance current draw, diagnose car battery drain (800A DC), and handle HVAC compressor inrush currents. Its all-in-one features like NCV and True-RMS make it the go-to tool for DIY projects, automotive repair, and professional electrical maintenance. The complete kit gets you working right out of the box Complete Kit, Ready to Use: This professional kit includes everything you need to start working immediately: a pair of 10A test leads with alligator clips, a temperature probe, a screwdriver, and a convenient storage pouch, offering great value and convenience Specification:
Max display:6000
DCV: 600mV/6V/60V/600V ±(0.5%+5)
ACV: 600mV/6V/60V/600V ±(0.8%+5)
ACA: 6A/60A/800A ±(1.5%+5)
Resistance: 600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ ±(0.8%+2)
Capacitance: 60nF/600nF/6uF/60uF/600uF/6mF/60mF ±(2.5%+5)
Frequency: 10Hz/100Hz/1kHz/10kHz/100kHz/1MHz/10MHz ±(0.5%+4)
Temperature: (-40~1000 )℃/(-40~1832 ) ℉ ±(1.0%+5) Resolution: 1℃/1℉
Clamp opens:26mm
Diode test:√
Continuity test: Less than 50Ω±10Ω
Low battery indicator:Approx. less than 2.4 V
Data hold:√
NCV:√
LIVE:√
Auto power off:About 15 minutes
Trms test:√
Clamp light:√
Backlight display:√
Input impedance:10MΩ
Sampling rate:3 times/s
AC frequency response: voltage 40-1kHz
Operation method:Auto or manual range

Battery: 3*AAA(1.5V) batteries
General Characteristic:
Meter weight:About 220g (including battery)
Meter size: 185mm×65mm×32mm

Notes:
1. All clamp meters can measure current through a single wire, if you put two wires into the clamp jaw, the reading will be zero, only from one wire, you will get exact digits.
2. Measure one wire in one time. If measure more than one wires in one time, the reading will be inaccurate.

Package Content:
1 x Clamp Meter
1 x K-Type Thermocouple
1 x Test Leads (Pair)
3 x 1.5V AAA Batteries(Included)
1 x User Manual
1 x Cloth Pouch
1 x Alligator Clip(1 pair)
1 x Screwdriver
