KUIDAMOS RS60-L 60mm Manual Precision Rotation Stage, 0.01 Accuracy — Open-Box, 18% Off

Application: Linear carrier table fine tuning table can be used for production machinery, testing equipment, optical experimental measurement, fine tuning displacement, precision positioning, quantitative movement, etc. Material And Precision: Our Aluminum Alloy Fine Tuning Sliding Table, the main body is made of aluminum alloy with black anodized surface, which is scratch proof and drop proof. linear Stage Table has a precision of 0.01m, and smooth movement, suitable for built in other equipment. plated locking screws, countersunk hole design, plated fine adjustment knob, carbide side head, Our fine tuning adopts precision manufacturing process, with , which can provide you with good use effect. Driving Method And Adjustment Angle: The driving method of this Manual Trimming Station Displacement is micrometer, load: 29.4N (3kgf). Rotating the can accurately adjust the angle of the to the approximate position, can achieve: 360 degrees manual coarse adjustment, rotation ± 5 degrees fine adjustment. NOTE:We like to provide customers with excellent value and excellent customer service. If you have any questions, you can us by email, and our If you have any questions, you can us by email, and our customer service will solve it for you within 24 hours.

Feature:

1. Can be used in production machinery, testing equipment, optical experimental measurement, fine-tuning displacement, precision positioning, quantitative movement and so on.
2. Main body aluminum alloy material, black anodized surface, scratch-resistant, anti-drop, anti-.
3. plated locking screw, designed with counterbore, plated fine adjustment knob, carbide side head, durable.
4. The driving method is a micrometer, which can be realized: manual coarse adjustment of 360 degrees, fine adjustment of rotation ± 5 degrees.
5. High precision, smooth movement, suitable to be built in other devices.

Specification:

Item Type: Linear Stage Trimming Platform
Model: RS60-L
Can be Realized: coarse adjustment 360 degrees, rotation precision adjustment ±5°
Material: Aluminum alloy (black anodized surface)
Table Diameter: Approx. 60mm / 2.4in
Moving Rail: Running-in installation
Drive Mode: Micrometer
Cursor Minimum Reading: Vernier Scale 0.1°
Micrometer Minimum Movement Reading: 0.015°
Load: 29.4N (3kgf)
Accuracy: 0.01m
Runout: 0.02mm
Parallelism: 0.03mm
Scope of Application: Production machinery, testing equipment, optical experimental measurement, fine-tuning displacement, precision positioning, quantitative movement and so on.

Package List:

1 x Linear Stage Trimming Platform
