Hydraulic Solenoid Flow Diverter Valve, Stackable Circuit Selector, 6-Port 2-Position 50-LPM 25-MPa (G 1/2, 12V Deutsch) — Open-Box, 22% Off

Versatile Hydraulic Circuit Addition - This MOP066 solenoid-operated valve ( Direct replacement for DV90-08, DV90-08S ) allows seamless integration of additional hydraulic circuits to your machinery. Its 6-port, 2-position design ensures versatility for use in agricultural, material handling, and construction equipment.

Exceptional Flow & Pressure Capacity - Handle demanding applications with ease, thanks to a maximum flow rate of 13 GPM (50 L/min) and operating pressure up to 3625 PSI (25 MPa). The G 1/2 or G3/8 or SAE 8 ( Size #8 ) O-ring ports provide a reliable, leak-free seal to optimize performance.

Durable Construction for Longevity - Built with a cast iron valve body treated with phosphating for enhanced durability. Its hardened and ground steel components are precision-engineered for minimal wear and smooth operation under high hydraulic loads.

Stackable & Efficient Design - This valve's stackable feature enables connection of up to five valves in series, adding up to three hydraulic functions. The spool is actuated by a high-performance 3-Prong or Deutsch 12V or 24V DC solenoid coils of your choises, making it suitable for both single and double-acting cylinders.

Advanced Spool Transition Functionality - Featuring a spool crossover function, all ports close intermittently during spool transition when the solenoid is energized, ensuring controlled operation. Designed for clean hydraulic performance, it meets NAS1638 Class 9 and ISO4406 Class 20/18/15 oil cleanliness standards.

The stackable circuit selector valves, type MOP.06.6, enable a single drive to operate six users with five elements connected in series. Powered by high-performance solenoids, these valves eliminate the need for external drainage. They are designed to handle high hydraulic power efficiently while minimizing pressure drops.
