Gigabit Ethernet Express PCI-E Network Card 10/100/1000Mbps SFP LAN Adapter Converter, PCI Express LAN Adapter Support Windows Server/Windows, Linux

Gigabit Network Speed — Fiber network card supports one SFP port, 1000Mbps internet access and 2000Mbps full-duplex bandwidth capacity. More System Compatible — Single port gigabit fiber network card fully compatible with Windows Server 2003/ 2008, Windows XP/7/10/Vista and Linux to provide added performance, flexible configuration and secure networking for users in a standard-based environment Advanced Networks Software — The PCI-E NIC (Network Internet Card) support networks software suite such as increased fault tolerance, bidirectional load balancing, port aggregation, jumbo frame up to 9216B, VLAN filtering packet processing and server management software Additional Functions — Fiber NIC integrated hardware acceleration that performs TCP/UDP/IP checksum offload and TCP segmentation. The host processing offloads accelerators frees CPU for application processing. Minimize overhead by reducing host bus traffic and CPU utilization Easy to install — Packed with both low profile bracket and full-height bracket, you can install the gigabit fiber PCI-E NIC in both standard and mini size computer case/server. Besides it’s easy to operate, plug and play

Overview:

Gigabit Fiber PCI-E NIC has a flexible design that fits almost any type of PCI bus, the standards-based management features and wide network operating system support help to ensure extensive compatibility with the latest server and networking environments.

Features:

Plug and Play, Easy to install

High bandwidth 1000Mbps Network Speed

Supports Full-Duplex Mode

Compliant to ACPI 2.0 specification

Support PCI-E 1.0a interface with 2.5GHz signaling

Flexible auto-negotiation performance, automatically scale with growing networks

Specifications:

Max Frame Size : 9216B

Transmitting Distance: Depends on SFP Module

Data Speed: 1000Mbits/s (Half duplex), 2000Mbits/s (Full duplex)

BUS Slot: PCI-E x1 Standard Slot

Consumption: Max 5.3W, DC 3.3V/1.6A

Standards:

IEEE 802.3z Gigabit Ethernet 1000Base-SX/LX

IEEE 802.3x Full-Duplex Flow Control

IEEE 802.1Q VLAN

IEEE 802.1p Priority Tagging

IEEE 802.1p Quality of Service

Drivers:

Windows Setup Installer (32- and 64-bit) for Yukon Controllers

DOS Diagnostic Utility for Yukon Devices

Kernel 2.6.x Linux Driver Install Package for Yukon Devices

Windows Vista x86 Driver (32-bit) for Yukon Devices

Windows XP/Server 2003 x64 Driver (64-bit) for Yukon Devices

Windows Vista x64 Driver (64-bit) for Yukon Devices

Windows Server 2008 SP2 32-bit Driver

Windows 7 & Server 2008 R2 x64 (64-bit)

Windows 7 & Server 2008 R2 32-bit Driver

Windows 10 (32-bit/64-bit) Device

Package:

Gigabit Fiber Optic LAN Card *1

Low-Profile Bracket *1
