CU433 Full Aluminum Radiator For 1966-1979 Ford F100 F150 F250 350 Bronco 1967 1968 1969 1972 Pickup Truck Radiators, 3 Row Radiator with 2 X 12" Fans Shroud Relay Kit, V8 Chevy Engine, AT MT

[Vehicle Fitment] Replacement for 1966 1967 1968 1969 1970 1971 1972 1973 1974 1975 1976 1977 1978 1979 Ford F100 F150 F250 F350 Bronco F-Series Truck; [Dimensions] Core Size: Height:19.25" x Width: 26.3" x Thick: 2.75''; Overall: Height 26.3" x Width: 29.5"; Inlet Diameter: 1.75" x Outlet Diameter: 2"; Trans Cooler Details: 1/8-27NPT(T) [Aluminum Radiator] The radiator is made of Aircraft AA5052 aluminum, constructed with 100% welded seams by TIG, brazed core technology and no epoxy. Direct fit and built to last long with high quality aluminum core. [Density Core] Cooling rows are spaced 3/8 inches apart, giving you 25% more rows within the core. Also, 14-16 cooling fins per inch give you approximately 1500 more cooling fins and provides 30% more cooling capacity. [No Leaking Worries] All radiator have to go through 5 checks in the whole process.100% leaking and pressure tested. Thickened packing(either carton or wooden box), foam with shock absorption.

ALLOYWORKS 3 Row Core Full Aluminum Complete Radiator with Aluminum Shroud, Fans, Thermostat Relay Kit, CNC Machined Radiator Cap will be your Best Choice!

For 1978-1979 Ford Bronco (351ci V8, 400ci V8)

For 1968-1969 Ford F-Series Truck (4.9L Straight 6-cylinder, 360ci V8, 390ci V8)

For 1970-1972 Ford F-Series Truck (360ci V8, 390ci V8)

For 1973-1975 Ford F-Series Truck (302ci V8, 360ci V8, 390ci V8)

For 1976 Ford F-Series Truck (302ci V8, 351ci V8)

For 1977-1979 Ford F-Series Truck (302ci V8, 351ci V8, 400ci V8)

For the year and models, please check the compatibility.

Only Fits Chevy V8 Engine Only!

(top hose on driver side, bottom hose on passenger side)

OE/OEM Part Number: 433,SBR433,CC433,CU433,DPI433,DPI433,DPI132,CU132

Radiator Details:

Color: Silver

Core Size: Height:19.25" x Width: 26.3" x Thick: 2.75''

Overall: Height 26.3" x Width: 29.5"

Inlet Diameter: 1.75" x Outlet Diameter: 2"

Upper Hose Fitting: PASS

Lower Hose Fitting: DRIVER

Trans Cooler Details: φ26*305*1/8-27NPT(T)

Mounting Specs: Ver - 16 1/2 Horizontal - 27 3/8

QC passed: Yes

Mounting Type: BRACKET

Material: Full Aluminium

Core and Tank: All Aluminum

High Performance Racing Spec.

Mounting Style: Screw-On

Radiator style: Downflow

Fit type: Vehicle Specific

Crafts: 100% Tig welded

Delivery: Local Delivery

Fitment Type: Direct Replacement

Placement on Vehicle: Engine Compartment

Surface Finish: Aircraft Grade Raw Aluminum

Petock Drain: OEM style brass petcock drain

Radiator Cap: CNC machined filler neck and cap

Transmission Cooler: Automatic and Manual

Aluminum Shourd & Fan Specification:

Volt:12v

Maximum Fan CFM: 1730 cfm

Fan Diameter (in): 12.050”

Thickness (in): 2.500”

Number of Blades: 10 S-Type blade

Maximum Fan RPM: 2,250 rpm

Blade Material: Plastic

Amp Draw: 12.70 amps

Includes the Mounting Tabs for an Easy Zip Tie Installation

Thermostat Kit Installation:

Universal fit for any automotive vehicle and electric fan.

Activates by grounding electric fans at preset temperature.

180'F turn-on temperature, 165'F turn-off temperature.

Probe typically threads into radiator, water outlet or manifold.

RED + connect directly to battery.

WHITE wire to ignition switch power source.

BLACK goes to thermos switch.

BLUE wire goes to the Fans.

Gentle Hint:

Parameters Meticulous Prior to Ordering.

Pls compare the overall width with your original radiator.

Professional installation is highly recommended! No Fitting Instructions Supplied!

Please contact us for installation video or other any problem.
