CNLonQcom 6 Strings Metal Solar PV Combiner Box DC500V 100A Circuit Breaker with Surge Protector, 15A Fuses and Radiator, Outdoor IP66 Waterproof for Solar Panels System

【Plug-and-Play Convenience】CNLonQcom's PV Combiner Box features pre-connected cables equipped with photovoltaic connectors, offering a seamless, plug-and-play experience. This design simplifies installation, making it quick and efficient, ideal for rapid deployment in solar energy systems.

【Robust Outdoor Protection】The high-strength Cold rolled steel casing of the CNLonQcom PV Combiner Box boasts an IP66 protection rating, ensuring it is resistant to UV rays and harsh outdoor conditions. This durability makes it an excellent choice for outdoor use in solar systems, as well as in RVs and yachts.

【Enhanced Circuit Protection】Equipped with a 500V 100A PV DC circuit breaker, 15A PV fuses, and a 500V surge protector, the CNLonQcom PV Combiner Box ensures comprehensive protection. It supports up to six PV array inputs, with each individual PV input array capable of handling a maximum current of 15A.

The LQT-500V-PV6 Solar Combiner Box is an advanced solution for efficient and safe solar energy management. Designed with a robust Cold rolled steel enclosure and an IP65 protection level, it is suitable for various environmental conditions. Featuring a sophisticated lightning protection system, it ensures the safety and longevity of your solar installations. The user-friendly, wall-mounted design makes it an ideal choice for residential and commercial solar energy applications.

【Trusted Expertise in PV Solutions】Trust in the CNLonQcom brand, a dedicated manufacturer and service provider deeply rooted in the photovoltaic industry. Our focus on manufacturing and servicing PV combiner boxes reflects our commitment to quality and reliability in solar energy solutions.

Product: LQT-500V-PV6 Solar Energy Combiner Box Maximum DC Voltage: 500V Maximum Input Strings: 6 Maximum Input Current per String: 15A Output String: 1 Maximum Output Conversion Current: 100A Lightning Protection Module Parameters: Nominal Discharge Current: 20kA Maximum Discharge Current: 40kA Enclosure Material: Cold rolled steel Protection Level: IP66 Installation: Wall-Mounted User Instructions: 1.Connect the positive and negative poles of the solar panel to the input terminals of the combiner box. Ensure the circuit breaker switch is in the ON position. 2.We recommend using a 6mm² cable.Do not reverse the photovoltaic input and output terminals, as it will hinder the normal operation of the output device and may cause damage to other equipment. 3.When maintaining or testing this combiner box, be cautious of live input and output terminals to avoid electric shock or damage to other devices. 4.After thunderstorms, inspect the lightning protection module. If the fault indicator is red, replace the module promptly. 5.Install in a ventilated, dry location, away from direct sunlight, high temperatures, and moisture to ensure optimal functionality. 6.The combiner box should be connected to the ground wire to protect against lightning damage to the device and solar panels.
