Planar Systems EPX100 100" 4K UHD LCD Display — Open-Box, 68% Off

Optimized for Digital Signage

4K resolution for life-like picture quality
High brightness of 700 nits for high impact messaging in high ambient lighting environments
Wide color gamut for deeper, richer color reproduction
OPS (Open Pluggable Specification) slot enables seamless integration of compatible digital signage hardware
Logo-free bezel
High Performance

4K@60Hz DisplayPort and HDMI connectivity including HDCP 2.2
Upscaling of Full HD or sub-1080p content to fill the entire 4K display area
24x7 operation and reliability to support extended use
Durable, all metal enclosure
Fanless for whisper-quiet operation
Configuration Flexibility

Mountable in either portrait or landscape orientation
VESA mount compatibility
Simultaneous multi-source viewing of 2 or 4 sources at one time

Pin-point clarity and accuracy for users at close viewing distances
Recognizes up to 20 simultaneous touch points at one time
Ships with a single license key of Planar® TouchMark™, the premier collaboration software solution. Additional licenses are available for purchase through our channel partners.
Perfect for annotation using the included, fine-tip passive stylus. Additional styli are available for purchase through our channel partners.

Display Resolution Ultra HD (3840 x 2160)
Screen Size 100 in. (diagonal)
Aspect Ratio 16:9
Display Active Area 86.7" x 48.8" (2203.2mm x 1239.3mm)
Viewing Angle (typ) 178°
Backlight LED
Brightness (typ) 700 nits
Response Time (typ) 6.5 ms
Frame Rate 60Hz
Contrast Ratio (typ) 3000:1
Pixel Pitch 0.5735mm x 0.5735mm
Color Gamut 98% NTSC
Display Color >1 billion colors. Full 10 bit data path
External Connections DisplayPort 1.2 x 2, HDMI 2.0 x 2 (HDCP 2.2), HDMI 1.4 x 2, VGA x 1, OPS x 1,
OPS USB 2.0 x 2, OPS USB 3.0 X 1
Modes 3840x2160 @ 24/25/30/50/60Hz; 1080p @ 24/25/30/50/60Hz; 1080i @ 50/60 Hz;
480p, 576p, 720p @ 50/60 Hz
Multi-Source Views PiP, Dual, Quad
Display Control IR, RS-232, LAN, Keypad
Cabinet Dimensions (W x H
x D)
89.3" x 50.7" x 4.46" (2267.4mm x 1288.7mm x 113.3mm)
Cabinet Dimensions with
Handles (W x H x D)
89.3" x 50.7" x 4.46" (2267.4mm x 1288.7mm x 113.3mm)
Orientation Landscape/Portrait
Bezel Width 1.3" (31.8mm) left and right, 1.0" (25.4mm) top and bottom
Weight 260 lbs (118 kg)
Weight (Shipping) 362 lbs (164 kg)
Audio Output PC Line Out, S/PDIF
Speakers 10W x 2 built-in
Enclosure Metal, Industrial
Auto Brightness Control Ambient light sensor
Mounting VESA: 600mm x 400mm, 600mm x 600mm
Fanless Yes
Line Voltage 100-240V; 50/60Hz
Power Consumption (typ) 425W (standby: Display Technology Direct-lit LED LCD
Haze 1%
Surface Treatment AG
Operating Temperature 0° to +40°C (32° to 104°F) up to 3000m
Humidity 20 - 85% RH (non-condensing)
Options / Features OPS slot, On/Off scheduling, Presets, TAA compliant
Approvals FCC Class A, CE, cTUVus
Recommended Usage Up to 24x7
In the Box EPX100 display, power cord, HDMI cable, IR cable, remote control, QTY 2 lifting eyebolts (attached to the top edge of the display), and cable clamp
