EPEVER 100A MPPT Solar Charge Controller 12V/24V/36V/48V DC Automatically Identifying System Voltage Max.PV 150V Solar Panel Regulator (Tracer 10415 an) — Open-Box, 30% Off

MPPT solar charge controller advanced MPPT technology & ultra-fast tracking speed, with tracking efficiency no less than 99.5%. High quality & low failure rate components of ST and Infineon to ensure the product's life. With the adaptive three-stage charging mode based on digital control circuit, Tracer AN series controllers can effectively prolong the life-cycle of battery and significantly improve the system performance. The load, utility or generator auto-control relays make it easy to compose the hybrid power system. All-around electronic protections, including overcharging, over discharging, and PV reverse polarity protection, effectively ensure the safer and more reliable operation of the solar system for a longer service time. It have battery temperature compensation function, real-time energy recording and statistical function, automatic over-temperature power reduction function. Hundred percent full load operation in working environment temperature range within charging & discharging. Wide range of maximum power point operating voltage, improved photovoltaic module utilization, rated charging power & charging current double automatic limiting function. Support 4 charging options: Sealed, Gel, Flooded and User. The isolated RS485 interface with standard MODBUS communication protocol and 5V power supply makes it easy for customer to expand the application, it support up to 8 charging in parallel to expand system and meet with different monitoring requirements, so that can be widely used for various applications, e.g. solar RV, household system and field monitoring etc. Features:

★ Advanced MPPT technology & ultra-fast tracking speed, with tracking efficiency no less than 99.5% 
★ Maximum DC/DC transfer efficiency is as high as 98.6%, full load efficiency is up to 98% 
★ Advanced MPPT control algorithm will minimize the MPP loss rate and loss time

★ The accuracy of the recognition and tracking at the highest point of multiple-peaks MPPT 
★ Auto control system to limit the charging power & current go over the rated value 
★ Support 4 charging options: Sealed, Gel, Flooded and User 
★ Battery temperature compensation function 
★ Real-time energy recording and statistical function 
★ Automatic over-temperature power reduction function 
★ Hundred percent full load operation in working environment temperature range within charging & discharging 
★ Support up to 8 units in parallel to expand system 
★ Load relay control external load switch signal to realize diversified load work modes

Tracer10415AN Technical datas :
Rated charge current: 100A
Nominal System Voltage: 12/24/36/48VDC or Auto
Battery Input Voltage Range: 8V～68V
Battery Type: Sealed(Default)/Gel/Flooded/User
Battery fuse: 150A/58V
Rated charge Power: 1250W/12V, 2500W/24V, 3750W/36V, 5000W/48V
Max. PV open circuit voltage: 150V(At minimum operating environment temperature) 138V(At 25℃ environment temperature)
MPP Voltage Range: (Battery Voltage+2V) ～144V(The maximum PV open circuit voltage must never exceed 138V or 180V at 25℃ environment temperature)
Tracking efficiency: ≥99.5%
Temperature compensate coefficient: -3mV/℃/2V(Default)
Self-consumption: 98mA/12V;60mA/24V;50mA/36V;46mA/48V
Grounding: Common negative grounding
Relay: Rated Value:5A/30VDC; Max. Value:0.5A/60VDC
RS485 interface: RS485(RJ45)

Package List:
1 x Tracer10415AN Solar Charge Controller
1 x User Manual
